Table 3.12 DIP Switch S1 Settings
Setting Value Description
V (right position) Voltage input (0 to 10 V): default setting
I (left position) Current input (4 to 20 mA or 0 to 20 mA)
Table 3.13 Parameter H3-01 Details
No. Parameter Name Description
Setting
Range
Default
Setting
MEMOBUS
Register
H3-01
Frequency ref.
(voltage/current)
terminal A1 signal
level selection
Selects the signal level for terminal A1.
0: 0 to +10 V, unipolar input (negative
frequency reference values are zeroed)
1: 0 to +10 V, bipolar input (negative
frequency reference changes the direction)
2: 4 to 20 mA
3: 0 to 20 mA
0 to 3 0 410H
3.9 Main Frequency Reference
64
YASKAWA ELECTRIC TOEP C710606 25B YASKAWA AC Drive J1000 Installation & Start-Up Manual
