5 Specifications and Dimensional Drawings of Cables and Peripheral Devices
5.5.12 Thermal Relays
5-38
(5) Selecting a Thermal Relay
When preparing the dynamic brake resistor and regenerative resistor separately, select a thermal relay by calcu-
lating the setting current of the thermal relay according to the value and capacity of the resistor being used, as
shown in the following equation.
Example for a JUSP-RA08
Select a thermal relay that has operating characteristics equivalent to those of the recommended product.
Refer to the following diagrams for the operating characteristics of the recommended thermal relays.
Setting current =
Resistance capacity (W) × 0.2
Resistance value (Ω)
Setting current =
2000 (W) × 0.2
2.4 (Ω)
14 A
Cold Start Characteristics (Ambient Temperature of 20
°
C) Hot Start Characteristics (Ambient Temperature of 20
°
C)
60
50
40
30
10
8
6
5
4
3
2
60
50
40
30
20
10
8
6
5
4
3
2
1
0.8
0.6
0.5
0.4
0.3
20
Multiplier of setting current
Multiplier of setting current
xln [A]
xln [A]
60
50
40
30
10
8
6
5
4
3
2
60
50
40
30
20
10
8
6
5
4
3
2
1
0.8
0.6
0.5
0.4
0.3
20
Operating time
Operating time
21 3 4 5 6 7 8 9 10 1521 3 4 5 6 7 8 9 10 15
Minutes
Seconds
Minutes
Seconds
Rated at 18 to 26 A min.
Rated at 12 to 18 A max.
Rated at 18 to 26 A min.
Rated at 12 to 18 A max.
