YASKAWA E7 Drive User Manual

Specifications C - 2
Standard Drive Specifications
The standard Drive specifications are listed in the following tables.
 Specifications by Model
Specifications are given by model in the following tables.
208-240Vac
Table C.1 200-240Vac Drive Specifications
Model Number CIMR-E7U
20P4 20P7 21P5 22P2 23P7 25P5 27P5 2011 2015 2018 2022 2030 2037 2045 2055 2075 2090 2110
Rated output capacity
(kVA)
1.2 1.6 2.7 3.7 5.7 8.8 12.0 17.0 22.0 27.0 32.0 44.0 55.0 69.0 82.0 110.0 130.0 160.0
Rated output current (A) 3.6 4.6 7.8 10.8 16.8 23.0 31.0 46.2 59.4 74.8 88.0 115.0 162.0 192.0 215.0 312.0
Max. output voltage (V)
3-phase; 200, 208, 220, 230, or 240Vac
(Proportional to input voltage)
Max. output frequency
(Hz)
120 Hz
Rated voltage (V)
Rated frequency (Hz)
3-phase, 200/208/220/230/240Vac, 50/60 Hz
Allowable voltage
fluctuation
+ 10%, - 15%
Allowable frequency fluc-
tuation
±5%
Measures
for power
supply har-
monics
DC Reactor Optional Built in
12-Pulse
Rectification
Not possible
Possible
*2
Note: The maximum applicable motor output is given for a standard 4-pole motor. When selecting the actual motor and Drive, be sure that the Drive's rated output
current is applicable for the motor's rated current.
A 3-wire transformer is required on the power supply for 12-pulse rectification.
O
utput rat
i
ngsPower supp
l
y c
h
aracter
i
st
i
cs
C
ontro
l
c
h
aracter
i
st
i
cs
