YASKAWA E7 Drive User Manual

Specifications C - 3
 480Vac
Table C.2 480Vac Drive Specifications
Model Number CIMR-E7U 40P4 40P7 41P5 42P2 43P7 45P5 47P5 4011 4015 4018
Rated output capacity (kVA) 1.4 1.6 2.8 4.0 5.8 9.5 13.0 18.0 24.0 30.0
Rated output current (A) 1.8 2.1 3.7 5.3 7.6 12.5 17.0 27.0 34.0 40.0
Max. output voltage (V) 3-phase; 380, 400, 415, 440, 460, or 480Vac (Proportional to input voltage.)
Max. output frequency (Hz) 120 Hz
Rated voltage (V)
Rated frequency (Hz)
3-phase, 380, 400, 415, 440, 460 or 480Vac, 50/60 Hz
Allowable voltage fluctuation + 10%, - 15%
Allowable frequency
fluctuation
±5%
Measures for
power supply
harmonics
DC Reactor Optional
12-pulse
Rectification
Not possible
Table C.3 480Vac Drive Specifications
Model Number CIMR-E7U 4030 4037 4045 4055
4075 4090 4110
4160 4185 4220 4300
Rated output capacity (kVA) 46.0 57.0 69.0 85.0 110.0 140.0 160.0 230.0 390.0
Rated output current (A) 67.2 77.0 96.0 125.0 156.0 180.0 240.0 304.0 506.0
Max. output voltage (V) 3-phase, 380, 400, 415, 440, 460 or 480Vac (Proportional to input voltage)
Max. output frequency (Hz) 120 Hz
Max. voltage (V)
Rated frequency (Hz)
3-phase, 380, 400, 415, 440, 460, or 480Vac, 50/60 Hz
Allowable voltage fluctuation + 10%, - 15%
Allowable frequency fluctuation ±5%
Measures for power
supply harmonics
DC Reactor Built in
12-Pulse
Rectification
Possible
*2
Note: The maximum applicable motor output is given for a standard 4-pole motor. When selecting the actual motor and Drive, be sure that
the Drive's rated output current is applicable for the motor's rated current.
A 3-wire transformer is required on the power supply for 12-pulse rectification.
O
utput rat
i
ngsPower supp
l
y c
h
aracter
i
st
i
cs
Control characteristics
O
utput rat
i
ngsPower supp
l
y c
h
aracter
i
st
i
cs
C
ontro
l
c
h
aracter
i
st
i
cs
