Electrical Installation 2 - 22
Fig 2.11 EMC Filter Layout
Metal plate
Grounding
Remove varnish or paint
Grounding
Remove varnish or paint
Motor cable
Length
Maximum of
Cable length
Maximum of 15.75”
82 feet
M
EMC
Filter
E7 Drive
