11.16 T: Motor Tuning
576 YASKAWA SIEPC71061737B GA800 Drive Technical Reference
◆ T4: EZ Tuning
No.
(Hex.)
Name Description
Default
(Range)
Ref.
T4-01
(3130)
EZ Tuning Mode
Selection
Sets the type of Auto-Tuning for EZOLV control.
0 : Motor Parameter Setting
1 : Line-to-Line Resistance
0
(0, 1)
1004
T4-02
(3131)
Motor Type Selection
Sets the type of motor.
0 : Induction (IM)
1 : Permanent Magnet (PM)
2 : Synchronous Reluctance (SynRM)
0
(0, 1, 2)
1005
T4-04
(3133)
Motor Rated Revolutions
Sets rated rotation speed (min
-1
) of the motor.
-
((40 Hz to 120 Hz) × 60 ×
2/E9-08)
1005
T4-05
(3134)
Motor Rated Frequency
Sets the rated frequency (Hz) of the motor.
Determined by E9-01 and
o2-04
(40.0 - 120.0 Hz)
1005
T4-06
(3135)
Motor Rated Voltage
Sets the rated voltage (V) of the motor.
200 V Class: 230.0 V, 400
V: 460.0 V
(200 V Class: 0.0 - 255.0
V,400 V Class: 0.0 -
510.0 V)
1005
T4-07
(3136)
Motor Rated Current
Sets the rated current (A) of the motor.
Determined by o2-04,
C6-01
(10% to 200% of the
drive rated current)
1005
T4-08
(3137)
Motor Rated Capacity
Sets the motor rated power in the units set in o1-58 [Motor Power Unit Selection].
Determined by E9-10
(0.10 - 650.00 HP)
1005
T4-09
(3138)
Number of Poles
Sets the number of motor poles.
Determined by E9-01
(2 - 48)
1005
