Parameter List
7
7.8 H: Terminal Functions
YASKAWA TOEPYAIH6B01A HV600 AC Drive Narrow Bypass Installation & Startup 195
No.
(Hex.)
Name Description
Default
(Range)
H1-76
(39F0)
RUN
Terminal S6 Off-Delay Time Sets the length of time necessary for Terminal S6 to be open before the drive removes the
programmed function.
0.00 s
(0.00 - 300.00 s)
H1-77
(39F1)
RUN
Terminal S7 Off-Delay Time Sets the length of time necessary for Terminal S7 to be open before the drive removes the
programmed function.
0.00 s
(0.00 - 300.00 s)
â—† H1-xx: MFDI Setting Values
Setting Value Function Description
3 Multi-Step Speed Reference
1
Uses speed references d1-01 to d1-08 to set a multi-step speed reference.
4 Multi-Step Speed Reference
2
Uses speed references d1-01 to d1-08 to set a multi-step speed reference.
5 Multi-Step Speed Reference
3
Uses speed references d1-01 to d1-08 to set a multi-step speed reference.
6 Jog Reference Selection Sets the drive to use the JOG Frequency Reference (JOG command) set in d1-17 [Jog Reference]. The JOG Frequency Reference
(JOG command) overrides the d1-01 to d1-08 [References 1 to 8] settings.
7 Accel/Decel Time Selection
1
Sets the drive to use Acceleration/Deceleration Time 1 [C1-01, C1-02] or Acceleration/Deceleration Time 2 [C1-03, C1-04].
8 Baseblock Command (N.O.) Sets the command that stops drive output and coasts the motor to stop when the input is ON.
ON : Baseblock (drive output stop)
OFF : Normal operation
9 Baseblock Command (N.C.) Sets the command that stops drive output and coasts the motor to stop when the input terminal is OFF.
ON : Normal operation
OFF : Baseblock (drive output stop)
A Accel/Decel Ramp Hold Momentarily pauses motor acceleration and deceleration when the terminal is turned ON, retains the output frequency that was
stored in the drive at the time of the pause, and restarts motor operation.
B Overheat Alarm (oH2) Sets the drive to display an oH2 [Drive Overheat Warning] alarm when the input terminal is ON. The alarm does not have an effect
on drive operation.
C Analog Terminal Enable
Selection
Sets the command that enables or disables the terminals selected in H3-14 [Analog Input Terminal Enable Sel].
ON : Input to the terminal selected with H3-14 is enabled
OFF : Input to the terminal selected with H3-14 is disabled
F Not Used Use this setting for unused terminals or to use terminals in through mode.
14 Fault Reset Sets the command to reset the current fault when the Run command is inactive.
Note:
The drive ignores the fault reset command when the Run command is active. Remove the Run command before trying to reset a
fault.
15
Fast Stop (N.O.) Sets the command to ramp to stop in the deceleration time set in C1-09 [Fast Stop Time] when the input terminal is activated while
the drive is operating.
17 Fast Stop (N.C.) Sets the command to ramp to stop in the deceleration time set in C1-09 [Fast Stop Time] when the input terminal is activated while
the drive is operating.
18 Timer Function Sets the command to start the timer function. Use this setting with Timer Output [H2-xx = 12].
19 PID Disable Sets the command to disable PID control when b5-01 = 1 or 3 [PID Mode Setting = Standard or Fref + PID Trim].
ON : PID control disabled
OFF : PID control enabled
1B Programming Lockout Sets the command to prevent parameter changes when the terminal is OFF.
ON : Programming Lockout
OFF : Parameter Write Prohibit
1E Reference Sample Hold Sets the command to sample the frequency reference at terminals A1 or A2 and hold the frequency reference at that frequency.
20 External Fault (NO-Always-
Ramp)
When the terminal activates, the drive ramps to stop in the selected deceleration time. Fault relay output terminal MA-MC will turn
ON, and MB-MC will turn OFF. The drive always detects external faults whether the drive is stopped or running.
21 External Fault (NC-Always-
Ramp)
When the terminal deactivates, the drive ramps to stop in the selected deceleration time. Fault relay output terminal MA-MC will
turn ON, and MB-MC will turn OFF. The drive always detects external faults whether the drive is stopped or running.
22 External Fault (NO-@Run-
Ramp)
When the terminal activates during run, the drive ramps to stop in the selected deceleration time. Fault relay output terminal MA-
MC will turn ON, and MB-MC will turn OFF. The drive does not detect external faults while the drive is stopped.
23 External Fault (NC-@Run-
Ramp)
When the terminal deactivates during run, the drive ramps to stop in the selected deceleration time. Fault relay output terminal MA-
MC will turn ON, and MB-MC will turn OFF. The drive does not detect external faults while the drive is stopped.
To Next Page
