YASKAWA HV600

7.11 o: Keypad-Related Settings
220 YASKAWA TOEPYAIH6B01A HV600 AC Drive Narrow Bypass Installation & Startup
No.
(Hex.)
Name Description
Default
(Range)
o1-26
(11AF)
RUN
Custom Monitor 3 Sets Custom Monitor 3. You can set a maximum of 12 monitors as user monitors. This parameter is
only available on an HOA keypad.
Note:
The default setting changes when b5-01 [PID Mode Setting] changes:
• b5-01 = 0 [Disabled]: 103
• b5-01 ≠ 0: 501
Determined by b5-01
(0, 101 - 1299)
o1-27
(11B0)
RUN
Custom Monitor 4 Sets Custom Monitor 4. You can set a maximum of 12 monitors as user monitors. This parameter is
only available on an HOA keypad.
0
(0, 101 - 1299)
o1-28
(11B1)
RUN
Custom Monitor 5 Sets Custom Monitor 5. You can set a maximum of 12 monitors as user monitors. This parameter is
only available on an HOA keypad.
0
(0, 101 - 1299)
o1-29
(11B2)
RUN
Custom Monitor 6 Sets Custom Monitor 6. You can set a maximum of 12 monitors as user monitors. This parameter is
only available on an HOA keypad.
0
(0, 101 - 1299)
o1-30
(11B3)
RUN
Custom Monitor 7 Sets Custom Monitor 7. You can set a maximum of 12 monitors as user monitors. This parameter is
only available on an HOA keypad.
0
(0, 101 - 1299)
o1-31
(11B4)
RUN
Custom Monitor 8 Sets Custom Monitor 8. You can set a maximum of 12 monitors as user monitors. This parameter is
only available on an HOA keypad.
0
(0, 101 - 1299)
o1-32
(11B5)
RUN
Custom Monitor 9 Sets Custom Monitor 9. You can set a maximum of 12 monitors as user monitors. This parameter is
only available on an HOA keypad.
0
(0, 101 - 1299)
o1-33
(11B6)
RUN
Custom Monitor 10 Sets Custom Monitor 10. You can set a maximum of 12 monitors as user monitors. This parameter is
only available on an HOA keypad.
0
(0, 101 - 1299)
o1-34
(11B7)
RUN
Custom Monitor 11 Sets Custom Monitor 11. You can set a maximum of 12 monitors as user monitors. This parameter is
only available on an HOA keypad.
0
(0, 101 - 1299)
o1-35
(11B8)
RUN
Custom Monitor 12 Sets Custom Monitor 12. You can set a maximum of 12 monitors as user monitors. This parameter is
only available on an HOA keypad.
0
(0, 101 - 1299)
o1-36
(11B9)
RUN
LCD Backlight Brightness Sets the intensity of the HOA keypad backlight. 5
(1 - 5)
o1-37
(11BA)
RUN
LCD Backlight ON/OFF
Selection
Sets the automatic shut off function for the LCD backlight.
0 : OFF
1 : ON
1
(0, 1)
o1-38
(11BB)
RUN
LCD Backlight Off-Delay Sets the time until the LCD backlight automatically turns off. 60 s
(10 - 300 s)
o1-39
(11BC)
RUN
Show Initial Setup Screen Sets the function to show the HOA keypad initial setup screen each time you energize the drive. This
parameter is only available on an HOA keypad.
0 : No
1 : Yes
1
(0, 1)
o1-40
(11BD)
RUN
Home Screen Display
Selection
Sets the monitor display mode for the Home screen. This parameter is only available on an HOA
keypad.
0 : Custom Monitor
1 : Bar Graph
2 : Analog Gauge
3 : Trend Plot
0
(0 - 3)
o1-41
(11C1)
RUN
1st Monitor Area Selection Sets the horizontal range used to display the monitor set in o1-24 [Custom Monitor 1] as a bar graph.
This parameter is only available on an HOA keypad.
0 : +/- Area ( - o1-42 ~ o1-42 )
1 : + Area ( 0 ~ o1-42 )
0
(0 - 1)
o1-42
(11C2)
RUN
1st Monitor Area Setting Sets the horizontal axis value used to display the monitor set in o1-24 [Custom Monitor 1] as a bar
graph. This parameter is only available on an HOA keypad.
100.0%
(0.0 - 100.0%)
