YASKAWA HV600

7.12 S: Special Applications
230 YASKAWA TOEPYAIH6B01A HV600 AC Drive Narrow Bypass Installation & Startup
◆ S5: Hand/Off/Auto Operation
No.
(Hex.)
Name Description
Default
(Range)
S5-01
(322F)
HAND Frequency Reference
Source
Sets the frequency reference source when HAND Mode is active.
0 : HAND Analog Input
1 : HAND Ref S5-05 or PID SP S5-06
2 : Set by b1-01
1
(0 - 2)
S5-02
(3230)
HAND/AUTO Switchover
During Run
Sets the function to enable or disable switching between HAND and AUTO Mode during run.
0 : Disabled
1 : Enabled
1
(0, 1)
S5-03
(3231)
RUN
HAND Mode PID Selection Sets the function to enable or disable PI function when HAND mode is active.
0 : Disabled
1 : Enabled
Note:
If b5-01 = 0 [PID Mode Setting = Disabled], the drive disables Hand Mode PID.
0
(0, 1)
S5-05
(3233)
RUN
HAND Frequency Reference Sets the frequency reference when HAND Mode is active, PID is disabled and S5-01 = 1 [HAND
Frequency Reference Source = HAND Ref S5-05 or PID SP S5-06].
0.00 Hz
(0.00 - 400.00 Hz)
S5-06
(3234)
RUN
HAND Setpoint Sets the System Setpoint when HAND Mode is active, PID is enabled and S5-01 = 1 [HAND
Frequency Reference Source = HAND Ref S5-05 or PID SP S5-06].
Note:
Parameters b5-46 [PID Unit Display Selection], b5-38 [PID User Unit Display Scaling], and b5-
39 [PID User Unit Display Digits] set the unit, range, and resolution.
0.0
(0.0 - 6000.0)
S5-07
(3235)
Operation HAND Key Sets the HAND key on the HOA keypad to let you switch between HAND Mode and AUTO Mode.
0 : Disabled
1 : Enabled
1
(0, 1)
S5-08
(3D31)
RUN
HAND Reference Prime
Loss Level
Sets the level at which the drive will detect the Loss of Prime in the pump.
Note:
• If these conditions occur at the same time, the drive will detect LOP [Loss of Prime]:
–The monitor set by Y1-18 [Prime Loss Detection Method] ≤ S5-08 for longer than Y1-20
[Prime Loss Time]
–Output frequency ≥ S5-05 [HAND Frequency Reference]
• The drive response to the Loss of Prime condition changes when the Y1-22 [Prime Loss
Selection] setting changes.
• Parameter Y1-18 [Prime Loss Detection Method] sets the units for this parameter.
0.0
(0.0 - 1000.0)
◆ S6: Protection
No.
(Hex.)
Name Description
Default
(Range)
S6-01
(3236)
Emergency Override Speed Sets the speed command for emergency override mode when S6-02 = 0 [Emergency Override Ref
Selection = Use S6-01 Reference].
Note:
Parameter default is lower-limited to E1-09. The default setting will automatically increase when
E1-09 > S6-01.
1.50 Hz
(1.50 - 60.00 Hz)
S6-02
(3237)
Emergency Override Ref
Selection
Sets the Emergency Override Speed Source:
0 : Use S6-01 Reference
1 : Use Frequency Reference
2 : System PID Mode
3 : Independent PID Mode
0
(0 - 3)
S6-03
(323A)
EMOVR Independent PID
Scale
Sets the scaling on the Emergency PID Feedback and Setpoint (if programmed) Analog Inputs.
Note:
• S6-05 [EMOVR Independent PID Unit Digit] sets the resolution for this parameter.
• S6-04 [EMOVR Independent PID Unit] sets the units for this parameter.
100.00
(0.10 - 600.00)
