5.3 Faults, Minor Faults, Alarms, and Error Codes Listed Alphabetically
YASKAWA TOEPYAIH6B01A HV600 AC Drive Narrow Bypass Installation & Startup 97
Display (Hex.) Name ALM LED Type Ref.
LT-1 (0035) Cooling Fan Maintenance Time Flashing Alarm 138
LT-2 (0036) Capacitor Maintenance Time Flashing Alarm 138
LT-3 (0043) SoftChargeBypassRelay MainteTime Flashing Alarm 138
LT-4 (0044) IGBT Maintenance Time (50%) Flashing Alarm 138
LWT (00A9) Low Water In Tank Flashing Alarm 138
ndAT Model,VolClass,Capacity Mismatch - Backup Function Runtime Error 150
NMS (009C) Setpoint Not Met Flashing Alarm 138
NMS (0429) Setpoint Not Met Illuminated Drive Fault 118
nSE (0052) Node Setup Error Illuminated Drive Fault 118
oC (0007) Overcurrent Illuminated Drive Fault 118
OD (009D) Output Disconnect Flashing Alarm 139
OD (042A) Output Disconnect Illuminated Drive Fault 119
oFA00 (0101) Option Not Compatible with Port Illuminated Drive Fault 119
oFA01 (0102) Option Fault/Connection Error Illuminated Drive Fault 119
oFA05 (0106) Option A/D Error Illuminated Drive Fault 119
oFA06 (0107) Option Communication Error Illuminated Drive Fault 119
oFA10 (0111) Option RAM Error Illuminated Drive Fault 120
oFA11 (0112) Option Ope Mode Error Illuminated Drive Fault 120
oFA12 (0113) Drive Receive CRC Error Illuminated Drive Fault 120
oFA13 (0114) Drive Receive Frame Error Illuminated Drive Fault 120
oFA14 (0115) Drive Receive Abort Error Illuminated Drive Fault 120
oFA15 (0116) Option Receive CRC Error Illuminated Drive Fault 120
oFA16 (0117) Option Receive Frame Error Illuminated Drive Fault 120
oFA17 (0118) Option Receive Abort Error Illuminated Drive Fault 120
oFA30 (0131) COM ID Error Illuminated Drive Fault 121
oFA31 (0132) Type Code Error Illuminated Drive Fault 121
oFA32 (0133) SUM Check Error Illuminated Drive Fault 121
oFA33 (0134) Option Receive Time Over Illuminated Drive Fault 121
oFA34 (0135) Memobus Time Over Illuminated Drive Fault 121
oFA35 (0136) Drive Receive Time Over 1 Illuminated Drive Fault 121
oFA36 (0137) CI Check Error Illuminated Drive Fault 121
oFA37 (0138) Drive Receive Time Over 2 Illuminated Drive Fault 121
oFA38 (0139) Control Reference Error Illuminated Drive Fault
122
oFA39 (013A) Drive Receive Time Over 3 Illuminated Drive Fault 122
oFA40 (013B) CtrlResSel 1Err Illuminated Drive Fault 122
oFA41 (013C) Drive Receive Time Over 4 Illuminated Drive Fault 122
oFA42 (013D) CtrlResSel 2Err Illuminated Drive Fault 122
oFA43 (013E) Drive Receive Time Over 5 Illuminated Drive Fault 122
oH (0003) Heatsink Overheat Flashing Alarm 139
oH (0009) Heatsink Overheat Illuminated Drive Fault 122
oH1 (000A) Heatsink Overheat Illuminated Drive Fault 123
oH2 (0004) External Overheat (H1-XX=B) Flashing Alarm 139
oH3 (001D) Motor Overheat (PTC Input) Illuminated Drive Fault 123
