5.3 Faults, Minor Faults, Alarms, and Error Codes Listed Alphabetically
98 YASKAWA TOEPYAIH6B01A HV600 AC Drive Narrow Bypass Installation & Startup
Display (Hex.) Name ALM LED Type Ref.
oH3 (0022) Motor Overheat (PTC Input) Flashing Alarm 139
oH4 (0020) Motor Overheat Fault (PTC Input) Illuminated Drive Fault 123
oL1 (000B) Motor Overload Illuminated Drive Fault 123
oL2 (000C) Drive Overload Illuminated Drive Fault 124
oL3 (0005) Overtorque 1 Flashing Alarm 140
oL3 (000D) Overtorque Detection 1 Illuminated Drive Fault 125
oL4 (0006) Overtorque 2 Flashing Alarm 140
oL4 (000E) Overtorque Detection 2 Illuminated Drive Fault 125
oL7 (002B) High Slip Braking Overload Illuminated Drive Fault 125
oPE01 Drive Capacity Setting Fault Flashing Parameter Setting Error 143
oPE02 Parameter Range Setting Error Flashing Parameter Setting Error 143
oPE03 Multi-Function Input Setting Err Flashing Parameter Setting Error 143
oPE05 Run Cmd/Freq Ref Source Sel Err Flashing Parameter Setting Error 144
oPE07 Analog Input Selection Error Flashing Parameter Setting Error 144
oPE08 Parameter Selection Error Flashing Parameter Setting Error 144
oPE09 PID Control Selection Fault Flashing Parameter Setting Error 144
oPE10 V/f Data Setting Error Flashing Parameter Setting Error 145
oPE11 Carrier Frequency Setting Error Flashing Parameter Setting Error 145
oPE16 Energy Saving Constants Error Flashing Parameter Setting Error 145
oPE29 Baud Rate Setting Error Flashing Parameter Setting Error 145
oPE33 Digital Output Selection Error Flashing Parameter Setting Error 145
oPE34 HAND/OFF/AUTO Input Setting Flashing Parameter Setting Error 146
oPE36 Bypass Energy Savings Setting Err Flashing Parameter Setting Error 146
oPr (001E) Keypad Connection Fault Illuminated Drive Fault 125
ov (0002) DC Bus Overvoltage Flashing Alarm 140
ov (0008) Overvoltage Illuminated Drive Fault 126
ov2 (0405) DC Bus Overvoltage 2 Illuminated Drive Fault 126
ovEr Too Many Parameters Changed - Not an alarm. 140
OV_PRESS (00CD) Over Pressure Detected Flashing Alarm 140
PASS Modbus Communication Test Flashing Not an alarm. 140
PE1 (0047)
PE2 (0048)
PLC Faults Illuminated Drive Fault 126
PF (0047) Input Phase Loss Flashing Alarm 140
PF (001B) Input Phase Loss Illuminated Drive Fault 126
rdEr Error Reading Data - Backup Function Runtime Error 150
SAFE (0062) Customer Safeties Flashing Alarm 141
SAFE (00C9) Safety Open Flashing Alarm 141
SC (0005) Short Circuit/IGBT Failure Illuminated Drive Fault 127
SCF (040F) Safety Circuit Fault Illuminated Drive Fault 127
SE (0020) Modbus Test Mode Error Flashing Alarm 141
SEr (003B) Speed Search Retries Exceeded Illuminated Drive Fault 127
SMK_ALRM (00CC) Smoke Alarm Active Flashing Alarm 141
STo (003C) Safe Torque OFF - Alarm 141
