5.17 Setting the Origin of the Absolute Encoder
5.17.1 Absolute Encoder Origin Offset
5-51
5
Basic Functions That Require Setting before Operation
5.17 Setting the Origin of the Absolute Encoder
5.17.1 Absolute Encoder Origin Offset
The origin offset of the absolute encoder is a correction that is used to set the origin of the
machine coordinate system in addition to the origin of the absolute encoder. Set the offset
between the absolute encoder origin and the machine coordinate system origin in Pn808
(Absolute Encoder Origin Offset).
After the SENS_ON (Absolute Data Request) command is received, the position in the machine
coordinate system (APOS) is set based on the absolute encoder position data and the setting
of Pn808.
5.17.2 Setting the Origin of the Absolute Linear Encoder
You can set any position as the origin in the following Linear Encoders.
• Mitutoyo Corporation
ABS ST780A Series or ST1300 Series
Models: ABS ST78A/ST78AL/ST13
• Renishaw PLC
EVOLUTE Series
Models: EL36Y-
• Renishaw PLC
RESOLUTE Series
Models: RL36Y-
Preparations
Always check the following before you set the origin of an absolute encoder.
• The parameters must not be write prohibited.
• The servo must be OFF.
Pn808
Absolute Encoder Origin Offset
Setting Range Setting Unit Default Setting When Enabled Classification
-1,073,741,823 to
1,073,741,823
1 reference unit 0 Immediately Setup
If the encoder position (X) is at the origin of the machine coordinate system (0), then Pn808
would be set to -X.
Position
Example
Pn808
Machine coordinate
Encoder coordinate
Absolute encoder origin
Origin of machine
coordinate system
Encoder position (X)
1. After you set the origin, the /S-RDY (Servo Ready) signal will become inactive because the
system position data was changed. Always turn the SERVOPACK power supply OFF and ON
again.
2. After you set the origin, the Servomotor phase data in the SERVOPACK will be discarded. If
you are using a Linear Servomotor without a Polarity Sensor, execute polarity detection again
to save the Servomotor phase data in the SERVOPACK.
Important
