14.2 Corresponding SERVOPACK and SigmaWin+ Function Names
14.2.1 Corresponding SERVOPACK Utility Function Names
14-3
14
Appendices
14.2 Corresponding SERVOPACK and SigmaWin+ Function Names
This section gives the names and numbers of the utility functions and monitor display functions
used by the SERVOPACKs and the names used by the SigmaWin+.
14.2.1 Corresponding SERVOPACK Utility Function Names
SigmaWin+ SERVOPACK
Button in
Menu
Dialog Box
Function Name Fn No. Function Name
Setup
Origin Search Fn003 Origin Search
Absolute Encoder Reset Fn008 Reset Absolute Encoder
Adjust the Analog Monitor Output
Fn00C Adjust Analog Monitor Output Offset
Fn00D Adjust Analog Monitor Output Gain
Adjust the Motor Current Detec-
tion Signal Offsets
Fn00E Autotune Motor Current Detection Signal Offset
Fn00F
Manually Adjust Motor Current Detection Signal
Offset
Multiturn Limit Setting Fn013
Multiturn Limit Setting after Multiturn Limit Dis-
agreement Alarm
Reset Option Module Configura-
tion Error
Fn014 Reset Option Module Configuration Error
Initialize Vibration Detection Level Fn01B Initialize Vibration Detection Level
Set Origin Fn020 Set Absolute Linear Encoder Origin
Reset Motor Type Alarm Fn021 Reset Motor Type Alarm
Software Reset Fn030 Software Reset
Polarity Detection Fn080 Polarity Detection
Tuning-less Level Setting Fn200 Tuning-less Level Setting
Easy FFT Fn206 Easy FFT
Parameters
Initialize Fn005 Initializing Parameters
Write Prohibition Setting Fn010 Write Prohibition Setting
Setup Wizard – –
Tuning
Autotuning without Host Refer-
ence
Fn201 Advanced Autotuning without Reference
Autotuning with Host Reference Fn202 Advanced Autotuning with Reference
Custom Tuning Fn203 One-Parameter Tuning
Adjust Anti-resonance Control Fn204 Adjust Anti-resonance Control
Vibration Suppression Fn205 Vibration Suppression
Moment of Inertia Estimation – –
Monitoring Product Information
Fn011 Display Servomotor Model
Fn012 Display Software Version
Fn01E Display SERVOPACK and Servomotor IDs
Fn01F
Display Servomotor ID from Feedback Option
Module
Test Opera-
tion
Jog Fn002 Jog
Jog Program Fn004 Jog Program
Alarms Alarm Display
Fn000 Display Alarm History
Fn006 Clear Alarm History
Solutions Mechanical Analysis – –
