Yealink SIP-T52S Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series/T5 Series/CP860/CP920 IP Phones
136
Boot Files, Configuration Files and Resource Files
When IP phones are configured with central provisioning method, they will request to
download the boot files, configuration files and resource files from the provisioning server.
The following sections describe the details of boot files, configuration files and resource files:
 Boot Files
 Configuration Files
 Resource Files
 Obtaining Boot Files/Configuration Files/Resource Files
Boot Files
Yealink IP phones running firmware version 81 or later support a new boot file in which you can
customize the download sequence of configuration files. It is efficiently for you to provision
your IP phones in different deployment scenarios, especially when you want to apply a set of
features or settings to a group of phones.
Note
The boot files are valid BOOT files that can be created or edited using a text editor such as
UltraEdit. The boot files are first downloaded when you provision the phones using centralized
provisioning (refer to Central Provisioning). The configuration parameters are not included in
the boot file. You can reference some configuration files that contain parameters in the boot
files to be acquired by all your phones and specify the download sequence of these
configuration files.
Yealink supports two types of boot files: common boot file and MAC-Oriented boot file.
During auto provisioning, the IP phone first tries to download the MAC-Oriented boot file (refer
to MAC-Oriented Boot File), and then download configuration files referenced in the MAC-
Oriented boot file in sequence from the provisioning server. If no matched MAC-Oriented boot
file is found, the IP phone tries to download the common boot file (refer to Common Boot File)
and then downloads configuration files referenced in the common boot file in sequence. If no
common boot file is found, the IP phone downloads the common CFG file (refer to Common
CFG File) and MAC-Oriented CFG file (refer to MAC-Oriented CFG File) in sequence.
The following figure shows an example of common boot file:
#!version:1.0.0.1
#The header above must appear as-is in the first line
include:config <configure/sip.cfg>
include:config “http://10.2.5.206/configure/account.cfg”
You can select whether to use the boot file or not for auto provisioning according to your
deployment scenario. If you do not use the boot file, proceed to Configuration Files on page
138. That is, you can also use the old mechanism for auto provisioning.

Yealink SIP-T52S Specifications

General

Touchscreen	-
Display diagonal	2.8 \
Backlight display	Yes
Display resolution	320 x 240 pixels
Lines quantity	16 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
Bluetooth version	2.1+EDR
Security algorithms	802.1x RADIUS, HTTPS, MD5
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Voice codecs	G.722, G.723, G.723.1, G.726, OPUS, iLBC
Volume control	Digital
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Front camera	No
Operating system installed	Linux

Weight and Dimensions

Depth	212 mm
Width	211.6 mm
Height	166.8 mm
