Administrator’s Guide for SIP-T2 Series/T19(P) E2/T4 Series/T5 Series/CP860/CP920 IP Phones
692
3. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
4. Click Confirm to accept the change.
To configure a multicast paging key via phone user interface:
1. Press Menu->Features->DSS Keys.
2. Select the desired DSS key.
3. Press or , or the Switch soft key to select Key Event from the Type field.
4. Press or , or the Switch soft key to select Multicast Paging from the Key Type
field.
5. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
6. Enter the multicast IP address and port number in the Value field.
7. Enter the desired channel in the Channel field.
8. Press the Save soft key to accept the change.
To configure a paging list key via phone user interface:
1. Press Menu->Features->DSS Keys.
2. Select the desired DSS key.
3. Press or , or the Switch soft key to select Key Event from the Type field.
4. Press or , or the Switch soft key to select Paging List from the Key Type field.
5. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
6. Press the Save soft key to accept the change.
Receiving RTP Stream
IP phones can receive an RTP stream from the pre-configured multicast address(es) on the
desired channel without involving SIP signaling, and can handle the incoming multicast paging
calls differently depending on the configurations of Paging Barge and Paging Priority Active.
Paging Barge
This parameter defines the priority of the voice call in progress, and decides how the IP phone
handles the incoming multicast paging calls when there is already a voice call in progress. If the
value of the parameter is configured as disabled, all incoming multicast paging calls will be
automatically ignored. If the value of the parameter is the priority value, the incoming multicast
