MyPBX Standard Administrator Guide
113
Type
Display the trunk type: PSTN.
Port
Display the relevant physical port of the trunk.
 BRI Trunk
Table 21-3 BRI Trunk Status
Status
BRI trunk status:
 Idle: the port is idle.
 Disconnected: there is no line connected to the port.
Trunk Name
Display the trunk name.
Type
Display the trunk type: BRI.
Port
Display the relevant physical port of the trunk.
 GSM/UMTS/CDMA Trunk
Table 21-4 GSM/UMTS/CDMA Trunk Status
Status
GSM/UMTS/CDMA trunk status:
 Idle: the port is idle.
 Busy: the port is in use.
 Failled: there is no SIM card inserted.
Signal
 : No signal.
 : Poor.
 : Average.
 : Good.
 : Excellent
Trunk Name
Display the trunk name.
Type
Display the trunk type: GSM/UMTS/CDMA.
Port
Display the relevant physical port of the trunk.
Network Status
Users could check the network status under Status→SystemStatus→Network
Status.
Figure 21-3 Network Status
