MyPBX Standard Administrator Guide
11
Extensions
This chapter explains how to create and configure extensions on MyPBX Standard. It
supports VoIP extensions and FXS extensions, go to PBX→Extensions→ FXS/VoIP
Extensions page to configure the extensions.
 FXS Extensions
 VoIP Extensions
FXS Extensions
MyPBX Standard supports up to 4 FXS extensions.To extend FXS extensions, S2
module or SO module should be installed on MyPBX.
After inserting the module, users could see FXS extensions on MyPBX web GUI.
Click to edit each FXS extension.
To change a FXS extension’s number, you have to click to delete the extension
first, then click to edit the extension’s number.
FXS Extension Configuration
The extension settings are divided into General Settings and Other Settings.
1) General Settings
Table 4-1 FXS Extension Configuration- General Settings
Items
Description
Extension
The numbered extension, which will be associated with this
particular User/Phone.
Port
Corresponding port for the FXS port, depends on which slot the
module was inserted.
Name
A character-based name for this user, e.g. “Bob Jones”.
Caller ID
The Caller ID will be used when this user calls another internal
extension.
Voicemail
 Enable Voicemail
Enable voicemail for the user.
 Voicemail Access PIN
The voicemail password (digits only) for the user to access
the voicemail box.
Mail Settings
 EnableSendVoicemail
Once enabled, the voicemailwillbe sent to a configured
