Optional Accessories (Sold Separately)
The optional accessories below are available for purchase separately. Check that all contents are
present and undamaged.
• Use the accessories specified in this manual. Moreover, use the accessories of this product only
with Yokogawa products that specify them as accessories.
• Use the accessories of this product within the rated range of each accessory. When using several
accessories together, use them within the specification range of the accessory with the lowest
rating.
Name Model Safety standard Note Manual No.
Isolated probe 700929 1000 Vrms CAT II 10:1 safety probe for the 701250, 701251, 720210,
720211, and 720254
IM 700929-01E
701947 1000 Vrms CAT II 100:1 safety probe for the 701250, 701251, 720210,
720211, and 720254
IM 701947-01E
Current probe 701930 300 Vrms CAT III 150 Arms, DC to 10 MHz. Used by connecting to a
probe power terminal (/P4 option) or a probe power
supply (701934; sold separately).
IM 701930-01E
701931 300 Vrms CAT III 500 Arms, DC to 2 MHz. Used by connecting to a
probe power terminal (/P4 option) or a probe power
supply (701934; sold separately).
IM 701931-01E
701932 300 Vrms 30 Arms, DC to 100 MHz. Used by connecting to a
probe power terminal (/P4 option) or a probe power
supply (701934; sold separately).
IM 701932-01E
701933 300 Vrms 30 Arms, DC to 50 MHz. Used by connecting to a
probe power terminal (/P4 option) or a probe power
supply (701934; sold separately).
IM 701933-01E
10:1 passive probe 701940 — For non-isolated input on the 701255: 600 V or less
For isolated input other than above: 42 V or less
IM 701940-01E
702902 1000V (DC+ACpeak)
CAT II
10:1 safety probe, wide temperature range, for isolated
BNC input, for the 701250, 701251, 720210, 720211,
and 720254
IM 702902-01EN
Differential probe 700924 1000 Vrms CAT III Switchable between 1000:1 and 100:1
Measurable voltage: 1400 Vpeak (1000 Vrms)
IM 700924-01E
700925 1000V (DC+ACpeak)
CAT III
Switchable between 100:1 and 10:1
Measurable voltage: 500 Vpeak (350 Vrms)
IM 700925-01E
701926 1000 Vrms CAT III Switchable between 1000:1 and 100:1
Measurable voltage: 7000 Vpeak (5000 Vrms)
IM 701926-01E
1:1 BNC safety
adapter lead
701901 1000 Vrms CAT II For use with the 701250, 701251, 720210, 720211,
and 720254. Used with the following items (which
are sold separately): the 701954, 701959, 758922,
758929, or 758921.
—
Measurement lead 758933 1000 Vrms CAT III 1 m in length; for use with the 701267. Used with
the following items (which are sold separately): the
701954, 701959, 758922, 758929, or 758921.
—
Alligator clip (dolphin
type)
701954 1000 Vrms CAT III Two pieces in one set (red/black) —
Safety mini-clip (hook
type)
701959 1000 Vrms CAT II Two pieces in one set (red/black) —
Alligator clip adapter 758922 300 Vrms CAT II Two pieces in one set —
Alligator clip adapter 758929 1000 Vrms CAT II Two pieces in one set —
Fork terminal adapter 758921 1000 Vrms CAT II Two pieces in one set (red/black). For 4 mm screws. —
Cable
1
366926 — For measuring low voltage of less than or equal to 42
V
—
Banana–alligator clip
cable
366961 — For measuring low voltage of less than or equal to 42
V for the 701261, 701262, or 701265
—
High-speed logic
probe
700986 — 42 V or less, 8 bits, non-isolated, response speed of 1
μs
—
Isolated logic probe 700987 250 Vrms CAT II 8 bits, each channel isolated, response speed of 20 ms
(for AC)
IM 700987-01E
1 m logic probe 702911 — 8 bits, non-isolated —
3 m logic probe 702912 — 8 bits, non-isolated —
Isolated logic
measurement lead
758917 1000 Vrms CAT II Two pieces in one set. Used with the 758922 or
758929 adapter. The adapters are sold separately.
—
Checking the Contents of the Package
