YOKOGAWA DL850E User Manual

x
IM DL850E-03EN
Name Model Safety standard Note Manual No.
External I/O cable 720911 — For external I/O —
1 m safety BNC
cable
701902 1000 Vrms CAT II — —
2 m safety BNC
cable
701903 1000 Vrms CAT II — —
Safety BNC-to-
banana adapter
758924 500 Vrms CAT II For the 701250, 701251, 701255, 720210, and 720211 —
Probe power supply 701934 — High current output power supply for external probes
(four outputs)
IM 701934-01E
Shunt resistor 438920 — 250 Ω ± 0.1% —
438921 — 100 Ω ± 0.1% —
438922 — 10 Ω ± 0.1% —
16-CH scanner box Accessory: Protection cover 1, Protection cover screw 1, Attaching plate 1, Binding screw 2
701953-
L1
— For the 720221; cable length: 1 m —
701953-
L3
— For the 720221; cable length: 3 m —
Cable 705926 — 1 m in length; for connecting the 720221 and 701953 —
705927 — 3 m in length; for connecting the 720221 and 701953 —
Bridgehead 701955 — NDIS, bridge resistance: 120 Ω IM 701955-01E
701956 — NDIS, bridge resistance: 350 Ω
701957 — DSUB, bridge resistance: 120 Ω, shunt-cal support IM 701957-01E
701958 — DSUB, bridge resistance: 350 Ω, shunt-cal support
Plug-on clip 701948 1000Vrms CAT II For the 700929/701947 IM 701948-01E
Long test clip 701906 1000Vrms CAT III For the 700924/701926 IM 701906-01E
Soft carrying case 701963 Has three pockets —
DC power cord
(Cigarette lighter
plug type)
701970 — For the DC power supply model (/DC) —
DC power cord
(Alligator clip type)
701971 — For the DC power supply model (/DC) —
GPS antenna A1058ER — GPS interface model (/C30) —
Sold individually.
1 Use cables (366926) that YOKOGAWA has been shipping since February 4, 1998. Cables (366926) shipped before this date
cannot be used in combination with the DL850E/DL850EV input modules.
Checking the Contents of the Package
