YOKOGAWA DL850E User Manual

xi
IM DL850E-03EN
Logic probes
702911 (1 m)/702912 (3 m)
Safety BNC cable
(1 m) 701902
Safety BNC cable
(2 m) 701903
Safety
BNC-to-banana
adapter
758924
1:1 BNC safety
adapter lead
701901
1
Isolated logic probe
700987
Differential probe
700924
Cable
366926
Banana–alligator
clip cable
366961
Isolated probe
700929
Current probe
701930
Isolated probe
701947
Alligator clip
adapter
(rated 1000 V)
758929
High-speed logic probe
700986
10:1 passive probe
701940
Alligator clip
(dolphin type)
701954
Fork terminal
adapter
758921
Current probe
701931
Safety miniclip
(hook type)
701959
Bridgehead
701955 (NDIS, 120 Ω)
Bridgehead
701956 (NDIS, 350 Ω)
Bridgehead
701957 (DSUB, 120 Ω)
Bridgehead
701958 (DSUB, 350 Ω)
Soft carrying case
701963
Current probe
701933
Current probe
701932
Isolated logic
measurement lead
758917
External I/O cable
720911
Probe power supply
701934
Cable
705927 (3m)
Alligator clip
adapter
(rated 300 V)
758922
16-CH scanner box
701953
2
Cable
705926 (1 m)
DC power cable
(Cigarette lighter plug type)
701970
DC power cable
(Alligator clip type)
701971
Measurement lead
758933
1
Differential probe
700925
Differential probe
701926
GPS antenna
A1058ER
Plug-on clip
701948
Long test clip
701906
1 The 1:1 BNC safety adapter lead (701901) and the measurement lead (758933) must be used with one of the following
accessories (which are sold separately): alligator clip (dolphin type: 701954), safety miniclip (hook type: 701959),
alligator adapter (758922 or 758929), or fork terminal adapter (758921).
2 The length of the 16-CH scanner box (701953) cable varies depending on the 16-CH scanner box suffix code.
PROBE 1
PROBE 2
PROBE 3
PROBE 4
OUTPUT
POWER SUPPLY
10:1 passive probe
(wide temperature range)
702902
Checking the Contents of the Package
