App-18
IM DL850E-03EN
CAN Bus Monitor Module, CAN & LIN Bus Monitor Module, and SENT
Monitor Moudule
Rate at Which Data Is Written to the Acquisition Memory
Number of Sub Channels Used 1 2 3 to 4 5 to 8 9 to 16 17 to 32 33 to 60
Sub Channel Sample Rate
(Data Update Rate)
100 k 100 k 100 k 100 k 100 k 100 k 100 k
Main Channel Sample
Rate Setting (S/s)
100 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
50 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
20 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
10 M 100 k 100 k 100 k 100 k 100 k 100 k 100 k
5 M 100 k 100 k 100 k 100 k 100 k 100 k 50 k
2 M 100 k 100 k 100 k 100 k 100 k 50 k 20 k
1 M 100 k 100 k 100 k 100 k 50 k 20 k 10 k
500 k 100 k 100 k 100 k 50 k 20 k 10 k 5k
200 k 100 k 100 k 50 k 20 k 10 k 5 k 2k
100 k 100 k 50 k 20 k 10 k 5 k 2 k 1k
50 k 50 k 10 k 10 k 5 k 2 k 1 k 500
20 k 20 k 10 k 5 k 2 k 1 k 500 200
10 k 10 k 5 k 2 k 1 k 500 200 100
5 k 5 k 1 k 1 k 500 200 100 50
2 k 2 k 1 k 500 200 100 50 20
1 k 1 k 500 200 100 50 20 10
500 500 100 100 50 20 10 5
200 200 100 50 20 10 5 2
100 100 50 20 10 5 2 1
50 50 10 10 5 2 1 –
20 20 10 5 2 1 – –
10 10 5 2 1 – – –
5 5 1 1 – – – –
If you set the sample rate (the main channel sample rate setting) of the DL850E/DL850VE to a rate
that exceeds the sub channel data update rate, all data within the sub channel data update interval
will be the same.
4-CH 1 MS/s, 16-Bit Isolation Module
Sample Rate of the 4-CH 1 MS/s, 16-Bit Isolation Module
Main Channel Sample
Rate Setting (S/s)
100 M 1 M
The sample rate (data update rate) of the 4-CH 1MS/s,
16-bit isolation module is always one-half that of the two-
channel module regardless of the number of sub channels
to be used.
50 M 1 M
20 M 1 M
10 M 1 M
5 M 1 M
2 M 1 M
1 M 500 k
500 k 100 k
200 k 100 k
100 k 50 k
50 k 10 k
20 k 10 k
10 k 5 k
5 k 1 k
2 k 1 k
1 k 500
500 100
200 100
100 50
50 10
20 10
10 5
5 1
Appendix 2 Relationship between the Main Channel Sample Rate, Sub Channel Data Update Rate, and Acquisition Memory Writing Rate
