App-24
IM DL850E-03EN
Operation Key
Soft Key Setting
(When Data Type is set to FastCH)
Endian Big
Start Bit
FastCH 1 0
FastCH 2 12
FastCH 3 0
Bit Size 12
Value Type Unsigned
Factor 1.00
Offset 0.00
Unit “”
(When Data Type is set to S&C)
Bit 0
Display ON
Label Bit0
Bit 1
Display ON
Label Bit1
Bit 2
Display ON
Label Bit2
Bit 3
Display ON
Label Bit3
V Zoom ×1.0
(When Data Type is set to SlowCH)
ID 0x00
Start Bit 0
Bit Size 12
Value Type Unsigned
Factor 1.00
Offset 0.00
Unit “”
(When Data Type is set to Error Trigger)
V Zoom ×1.0
CH1 to 16 (4CH 1M16 (720254))
V/div 50.00 V/div
Position 0.00 div
Label
Sub channel number 1 CH<x>_1
Sub channel number 2 CH<x>_2
Coupling DC
Probe 10:1
BandWidth Full
V Scale DIV
V Zoom ×1
Offset 0.00 V
Invert OFF
Linear Scale OFF
START/STOP
STOP
TIME/DIV
1 ms/div
ACQUIRE
Record Length 10 k
Acquisition Mode Normal
Trigger Mode Auto
Acquisition Count Infinite
HD Recording OFF
Time Base Int
DUAL CAPTURE
Mode OFF
Operation Key
Soft Key Setting
Capture Setup
Time/div 100 µs/div
Capture Length 10 k
Capture Mode Auto
Select Number Current
Mag 100 µs/div
Position 0.0 div
Window ON
Main Ratio 50%
Window Layout Side
Format Main
Event Display OFF
FILE
Save_Waveform
Auto Naming Numbering
Data Type Binary
Range Main
Save_Setup
Auto Naming Numbering
Save_Others
Auto Naming Numbering
Data Type Screen Image
Format PNG
Color ON
MENU
Waveform Save ON
Waveform Save Setup
Auto Naming Numbering
Data Type Binary
Image Save OFF
Image Save Setup
Auto Naming Numbering
Image Format PNG
Color ON
Back Ground Normal
DISPLAY
Format Quad
Extra Window OFF
Graticule Grid
Scale Value ON
Setup
Allocation Mode Auto
Trace Label OFF
Dot Connect Line
Accumulate OFF
Manual Event OFF
Ch. Information Narrow
X-Y
Window1/2 OFF
Display OFF
Start Point –5 div
End Point 5 div
MODE
Auto
POSITION/DELAY
Position 50.0%
Delay 0.0 µs
SIMPLE/ENHANCED
Setting Simple
Source CH1
Slope Rising
Level 0 V
Appendix 4 Default Values
To Next Page
