1-8
IM WT3001E-51EN
• When Measuring Using a Fixed Range (When Auto Range Is Set to OFF)
6.
Press the cursor keys to select Range under Speed.
7.
Press SET. An input range selection box appears.
8.
Press the cursor keys to select a value between 20 V to 1 V.
9.
Press SET to confirm the input range.
• Selecting the Analog Input Range of the Torque Signal
• Selecting Auto Range
2.
Press the cursor keys to select Auto Range under Torque.
3.
Press SET. An auto range selection box appears.
4.
Press the cursor keys to select ON or OFF.
5.
Press SET to confirm the auto range setting.
• When Measuring Using a Fixed Range (When Auto Range Is Set to OFF)
6.
Press the cursor keys to select Range under Torque.
7.
Press SET. An input range selection box appears.
8.
Press the cursor keys to select a value between 20 V to 1 V.
9.
Press SET to confirm the input range.
1.4 Selecting the Analog Range
