Getting Started
18
• Connect the power supply to power on the device.
• Configure the device.
• Mount the device with the mounting bracket.
• Setup a Google account.
Inserting the microSD Card (Optional)
The microSD card slot provides secondary non-volatile storage. The slot is located on the back of the
device to the right of the audio jack. Refer to the documentation provided with the card for more
information, and follow the manufacturer’s recommendations for use.
CAUTION: Follow proper electrostatic discharge (ESD) precautions to avoid damaging the microSD card.
Proper ESD precautions include, but are not limited to, working on an ESD mat and ensuring that the oper-
ator is properly grounded.
To install the microSD card:
1. Remove the device from the mounting bracket, if installed.
2. Slide the microSD card, connectors down, into the device as shown in Figure 9.
Figure 9 Inserting microSD Card
Mounting the Device
Each configuration of the device requires the appropriate mounting bracket to mount the device to a wall or
other flat surface. The diameter of the holes for the wall screws is 5.8mm (0.228 in).
NOTE: Device measurements in Figure 10, Figure 11 and Figure 12 are in millimeters.
