Data Capture
66
Scanning with Internal Imager
To read a barcode, a scan-enabled app is required. The device contains the DataWedge app that allows
the user to enable the imager, decode the barcode data, and display the barcode content.
To scan with the internal imager:
NOTE: Configure the imager illumination setting in the DataWedge application.
1. Ensure that an application is open on the device and a text field is in focus (text cursor in text field).
2. Place the barcode in the field of view of the device’s scan window. Ensure the barcode is within the
scanner’s aiming pattern.
Figure 34 Imager capturing
3. By default, a beep sounds indicates that the barcode was decoded successfully. Note that when the
device is in Pick List Mode, the device does not decode the barcode until the center of the illuminated
line or dot touches the barcode.
