Data Capture
71
2.
Ensure that an app is open on the device and a text field is in focus (text cursor in text field).
Figure 44 Barcode Scanning with RS6000
3. Point the RS6000 at a barcode.
4. Press and hold the trigger.
The red laser aiming pattern turns on to assist in aiming. Ensure the barcode is within the area formed
by the cross-hairs in the aiming pattern. The aiming dot increases visibility in bright lighting conditions.
The RS6000 LEDs light green and a beep sounds to indicate the barcode was decoded successfully.
When the RS6000 is in Pick List mode, the RS6000 does not decode the barcode until the center of the
crosshair touches the barcode.
Figure 45 RS6000 Aiming Pattern
Figure 46 RS6000 Pick List Mode with Multiple Barcodes in Aiming Pattern
5. The captured data appears in the text field.
