Zebra CC600 Product Reference Guide

Data Capture
80
e.
Scan the barcode below to place the Bluetooth Ring Scanner in HID mode.
Figure 61 RS507 Bluetooth HID Barcode
Figure 62 RS6000 Bluetooth HID Barcode
3. Remove the battery from the Bluetooth Ring Scanner.
4. Re-install the battery into the Bluetooth Ring Scanner.
5. Swipe down from the Status bar to open the Quick Access panel and then touch .
6. Touch Bluetooth.
7. Touch Pair new device. The device begins searching for discoverable Bluetooth devices in the area
and displays them under Available devices.
8. Scroll through the list and select RS507/RS507X or RS6000.
The device connects to the RS507/RS507X or RS6000 and Connected appears below the device
name. The Bluetooth device is added to the Paired devices list and a trusted (“paired”) connection is
established.
A notification appears on Notification panel and the icon appears in the Status bar.
