30 R110Xi/R170Xi User Guide 23063L-003 Rev. 1 12/6/04
Printer Operation
Loading Ribbon
7. See Figure 24. Bring the ribbon under the ribbon take-up spindle, and wrap it around the
spindle counter-clockwise.
Figure 24 • Winding Ribbon around the Ribbon Take-up Spindle
8. Turn the ribbon take-up spindle counterclockwise until the ribbon stays on it, as shown.
9. Close the printhead.
1
Ribbon leader
2
Ribbon take-up spindle
1 2
To Next Page
