START-UP
Carl Zeiss Connecting the Distribution Box for Laser Safety Cell Observer SD
46 423638-7044-001 M60-2-0021 e 01/2009
In addition to that, the distribution box for laser safety has an optional connection for a door interlock
switch (
Fig. 3-9/7).
You are advised to contact your Laser Safety Officer for connection of the door switch.
• Unplug the green plug (Fig. 3-9/7) from the distribution box for laser safety.
• Loosen the two screws of the plug and remove the jumper cable.
• Connect the cable of the door interlock switch to the plug and tighten the two screws.
• Insert the plug (
Fig. 3-9/7) again into the distribution box for laser safety.
