OPERATION
Cell Observer SD Dual Cam Option Carl Zeiss
M60-2-0021 e 01/2009 423638-7044-001 59
4.9 Dual Cam Option
The Dual Cam option allows you to connect two cameras to a spinning disc unit.
The Dual Cam option may solely be retrofitted by Service Department personnel of
Carl Zeiss MicroImaging GmbH or expert technicians specifically authorized to perform such
work!
To switch between the two camera channels, move the push rod in or out as necessary (
Fig. 4-1/4). The
lateral camera channel will be active when the push rod is fully inserted, the upper camera channel when
the rod is fully extracted.
Where a secondary color splitter is installed, the short-wave emission light portion will be directed onto
the lateral camera adapter and the long-wave emission light portion onto the upper camera adapter
when the push rod is fully extracted.
