Zeiss Cell Observer SD - Switching the System off

OPERATION
Cell Observer SD Switching the System off Carl Zeiss
M60-2-0021 e 01/2009 423638-7044-001 55
4.3 Switching the System off
4.3.1 Turning the Cell Observer SD Off
• Press the Shutter key (
Fig. 4-1/1) or use the related Axio Vision software tool to close the shutter.
• Turn the laser off (refer to sections
4.3.2 and 4.3.3).
• Turn the key switch (
Fig. 4-1/2) at the spinning disc unit into position OFF.
The control LED (
Fig. 4-1/3) extinguishes.
• Transfer the main power switch (
Fig. 4-4/1) of the CSU-X1 control box into Off position.
• Turn the microscope off.
4.3.2 Turning the Multiline Argon Laser Off
• Set the laser power controller to minimum level on completion of a working session (potentiometer
(
Fig. 4-5/2) in left stop position).
• Transfer the laser power controller into Standby mode by flipping the toggle switch (
Fig. 4-5/3)
down.
• Turn the key switch (
Fig. 4-6/2) into position 0 to turn the laser off. The fan will continue to run for
some minutes until the laser head cooled down.
Once the fan has switched off, you can turn the On/Off switch (
Fig. 4-6/3) at the power supply
unit off.
4.3.3 Turning the Multi Laser Module Off
• Turn the key switch (
Fig. 4-8/1) of the laser controller into position OFF.
This will shut all laser lines down. The red control LED’s extinguish.
• Terminate your AxioVision software session.
• Toggle the On/Off switch into position 0 to turn the signal distribution box off (
Fig. 4-7/1).
The green control LED (built into On/Off switch) extinguishes.
• Turn the power strip off. This will cut power supply to the multi laser module.
