2.11.3 Clutch Functions
2.11.3.1 Basic Clutch Functions
The following functions are available for all types of clutches.
• C0 Clutch Pressure Interlock -
Selects the Clutch Pressure Interlock option.
• C1 Clutch Interlock Delay -
Determines when the Clutch Pressure Interlock becomes active.
• C2 Proportional Pause -
Selects between an In-Gear, Neutral, or Fixed Neutral delay.
• C3 Proportional Pause Time -
Selects the maximum delay during a full speed reversal.
• C4 Proportional Pause Ratio -
Determines if the Ahead and Astern reversal times are the
same or if Astern is one half of Ahead.
Detail information on each function is found in Section 5.7.1: Clutch Functions.
2.11.3.2 Clutch Servo Functions
This section along with the Section 2.11.3.1: Basic Clutch Functions Section allows the adjustment of
Clutch servo related items:
• C5 Clutch Servo Direction -
Determines if the servo pushes or pulls for Ahead and Astern.
• C6 Clutch Ahead -
Adjusts the amount of clutch servo travel in Ahead.
• C7 Clutch Astern -
Adjusts the amount of clutch servo travel in Astern.
Detail information on each function is found in Section 5.7.1.2: Clutch Servo Functions.
2.11.3.3 Clutch Solenoid Functions
This section along with the Basic Clutch Functions Section allows the adjustment of Clutch Solenoid
related items:
• C5 Shift Solenoid Type -
Selects the approximate current levels for the 12 or 24 VDC ZF
Hurth Solenoids.
• C6 ZF-Hurth Duty Cycle Ahead -
Fine tunes the maximum current level to the Ahead
Proportional Solenoid.
• C7 ZF-Hurth Duty Cycle Astern -
Fine tunes the maximum current lever to the Astern
Proportional Solenoid.
Detail information on each function is found in Section 5.7.1.3: Clutch Solenoid Functions.
2.11.4 Troll Functions
2.11.4.1 Basic Troll Functions (All Processors with Troll Function)
The following functions are available for all Processors with the option of Trolling Valve Control feature.
• L4 Troll Throttle Limit
- Allows an increase in Throttle while slipping the Clutch.
• L5 Troll Pulse Duration
- Selects the amount of time for Troll Pulse Percentage.
• L6 Troll Pulse Percentage
- Selects the percentage of Troll Minimum when first engaging the
Clutch with Troll.
Detail information on each function is found in Section 5.7.2: Troll Functions.
2.11.4.2 Troll Servo Functions
This section, along with the Basic Troll Functions Section allows the adjustment of servo Trolling Valve
related items:
• L0 Troll Enable and Control Head Lever Range
- Turns Troll ON (Integrated) and sets the
degrees of Control Head lever movement dedicated to Troll.
• L1 Troll Servo Direction
- Determines if the Troll push-pull cable is retracted or extended at
Lock-up.
• L2 Troll Minimum Pressure
- Adjusts the Troll push-pull cables position at minimum Shaft
rotation.
• L3 Troll Maximum Pressure
- Adjusts the Troll push-pull cable’s position at maximum Shaft
rotation (not maximum pressure).
Detail information on each function is found in Section 5.7.2: Troll Functions.
NOTE: The following Troll Functions are available for the 9001 Troll Actuator or Integrated Servo Troll
command.
To Next Page
