TROUBLESHOOTING
MM9000 Rev C.8 01/13 Page 169
MM9000 ClearCommand User Manual
Troubleshooting
10.9.2 Servo 1 Clutch Problem Causes and Solutions
10.9.3 Servo 1 Troll Problem Causes and Solutions
Table 10-10: Servo 2 Throttle Problem Causes and Solutions
Error
No.
Causes Solutions
62
a. Excessive Clutch Push-Pull cable travel. a. Readjust Function Code C6 and or C7.
b. The load on the Push-Pull cable exceeds 40 Lbs. b.
Contact a certified Marine Transmission
technician to determine the cause of the
excessive load.
c. The Push-Pull cable is defective. c. Replace the Push-Pull cable.
d. The Processor’s Clutch Servo (Servo 1) is defective. d. Replace the Processor.
e. Low battery voltage. e.
Charge, repair or replace the battery, charging
system or power distribution system.
63
a.
The Clutch Servo’s feedback potentiometer is out of
calibration.
a.
Replace the Processor or calibrate the
potentiometer.
b.
The Clutch Servo’s feedback potentiometer is
defective.
b.
Replace the Processor or replace the
potentiometer.
c. The Processor’s Circuit Board is defective. c. Replace the Processor or the Circuit Board.
64
a.
The Clutch Servo’s feedback potentiometer is out of
calibration.
a.
Replace the Processor or calibrate the
potentiometer.
b.
The Clutch Servo’s feedback potentiometer is
unplugged from the Circuit Board.
b.
Plug the feedback potentiometer’s brown plug
into the Circuit Board.
c.
The Clutch Servo’s feedback potentiometer is
defective.
c.
Replace the Processor or the feedback
potentiometer.
d. The Processor’s Circuit Board is defective. d. Replace the Processor or the Circuit Board.
Table 10-11: Servo 1 Clutch Problem Causes and Solutions
Error
No.
Causes Solutions
62
a. Excessive Troll Push-Pull cable travel. a. Readjust Function Code L2 and / or L3.
b. The load on the Push-Pull cable exceeds 40 Lbs. b.
Contact a certified Marine Transmission
technician to determine the cause of the
excessive load.
c. The Push-Pull cable is defective. c. Replace the Push-Pull cable.
d. The Processor’s Troll Servo (Servo 1) is defective. d. Replace the Processor.
e. Low battery voltage. e.
Charge, repair or replace the battery, charging
system or power distribution system.
63
a.
The Troll Servo’s feedback potentiometer is out of
calibration.
a.
Replace the Processor or calibrate the
potentiometer.
b.
The Troll Servo’s feedback potentiometer is
defective.
b.
Replace the Processor or replace the
potentiometer.
c. The Processor’s Circuit Board is defective. c. Replace the Processor or the Circuit Board.
