5.6.2 Throttle Functions
5.6.2.1 Throttle Basic Functions
5.6.2.1.1 Function Code E5 – Throttle Pause Following Shift
The available Values for this Function are 00.0 seconds to 05.0 seconds.
The Default Value is 00.5 seconds.
This Function programs the amount of delay between the point that Clutch engagement is
commanded and throttle is allowed to increase above Idle.
To change the Value (Refer to Sections Section 5.2: Activating Set Up Mode and Section
5.3: Storing Values To Memory):
A Scroll to Function Code E5.
B Activate Set Up Mode.
C Scroll Up or Down to the desired Value.
D Store the Value to memory.
Figure 5-16: Display LED Function E5 Set Up Activated
5.6.2.1.2 Function Code E6 – High Idle
This Function Code Programs the RPM of the second, elevated Idle.
The available Values for this Function are 00.0 to 20.0% of Throttle Maximum.
The Default Value is 00.0%.
The Value selected is a percentage of the Value selected in Function Code E3 – Throttle
Maximum.
To change the Value (Refer to Sections Section 5.2: Activating Set Up Mode and Section
5.3: Storing Values To Memory):
A Scroll to Function Code E6.
B Activate Set Up Mode.
C Scroll Up or Down to the desired Value.
D Store the Value to memory.
Figure 5-17: Display LED Function E6 Set Up Activated
NOTE: This Function is typically programmed during Dock Trials. Refer to the appropriate Section 6.8: Throttle
Pause Following Servo Shift, or Section 6.9: Throttle Pause Following Solenoid Shift.
NOTE: This Function is typically programmed during Dock Trials or Sea Trials. Refer to Section 6.5: High Idle.
