A4 Neutral Indication Tone
00 – No Tone
01 – Tone upon engaging Neutral Detent
02 – Tone upon shifting to Neutral
THROTTLE FUNCTIONS (Section 5.6.2: Throttle Functions)
E0
Engine Throttle Profile OR
Throttle Servo Direction
01 - Caterpillar (PWM) (* to 92%)
02 - Cummins Centry (Voltage) (0.9 to 4.5 VDC)
03 - Cummins Quantum (Voltage) (0.9 to 1.2 - 4.0 VDC)
04 - Detroit Diesel (Voltage) (0.64 to 4.65 VDC)
05 - MTU or MAN (Current) (4.0 to 20.0 mA)
06 - Scania (Voltage (0.42 to 2.95 VDC)
07 - John Deere (Voltage) (0.5 to 4.5 VDC)
08 - Volvo (Voltage) (0.6 to 3.6 VDC)
09 - Detroit Diesel (Frequency) (120.64 to 360.9 Hz)
10 - Detroit Diesel (Frequency) (120.64 to 463.5 Hz)
20 – Pull [Retracted] for Throttle Increase
21 – Push [Extended] for Throttle Increase
E1 Throttle in Neutral 00.0 to 25.0% of Throttle Range
E2 Throttle Minimum
00.0 to 20.0%
Will always be 10% or more below Maximum.
E3 Throttle Maximum
10.0 to 100.0%
Will always be 10% or more above Minimum.
E4 Throttle Maximum Astern 00.0 to 100.0% of Throttle Maximum
E5
Throttle Pause Following
Shift
00.0 to 05.0 Seconds
E6 High Idle 00.0 to 20.0% of Throttle Maximum
THROTTLE FUNCTIONS continued (Section 5.6.2: Throttle Functions)
E7 Synchronization
00 – Equal Throttle (Open Loop) Synchronization
01 - Active (Closed Loop) Synchronization (reverts to Equal if Tach Signal lost)
02 - No Synchronization
03 - Active (Closed Loop) Synchronization (no synchronization if Tach Signal is lost)
CLUTCH FUNCTIONS (Section 5.7.1: Clutch Functions)
C0 Clutch Pressure Interlock
00 – Not Installed
01 – Installed
02 – Throttle Clutch Pressure Interlock Mode
C1 Clutch Interlock Delay 00.5 to 10.0 Seconds
C2 Proportional Pause
00 – In-Gear
01 – Neutral
02 – Fixed Neutral Delay Enabled (NOTE: If C2 is set to 02, C3 will set Fixed Neutral
Delay duration.)
C3 Proportional Pause Time 00 to 99 Seconds
Table 5-1: Function Codes
Function
Code
Function Name Value Range or Options
