April 2019 Nightingale PPM3 User's Guide 12-11
Managing Alarms
SpO
2
Conditions:
Condition
Display
Value
Alarm
Grade
Message
Annunciation
Type
SpO
2
within limits
<NUM>
None
None
None
SpO
2
< LL
<NUM>
Medium
SpO
2
< LL
Persistent
SpO
2
> UL
<NUM>
Medium
SpO
2
> UL
Persistent
SpO
2
Bad Probe
---
Low
SpO
2
replace sensor
One Time
SpO
2
Cannot regulate LED
intensity (after start-up/standby)
<Blank>
None
None
Persistent
SpO
2
Cannot regulate LED
intensity (after finger in probe)
---
Low
SpO
2
check sensor
placement
Persistent
SpO
2
Pulsations Too Weak
---
Low
SpO
2
weak signal
Persistent
SpO
2
Probe is disconnected
(after start-up/standby)
<Blank>
None
None
Persistent
SpO
2
Probe is disconnected
(after finger in probe)
---
Low
SpO
2
unplugged
One Time
SpO
2
motion artifact
---
Low
SpO
2
artifact
Persistent
PR Conditions:
Note ‒ When PR is sourced from SpO
2
, the Pulse Rate is labeled in cyan as "HR (SpO2)"
in the HR parameter box. When PR is sourced from an ART-labeled IBP, the PR is
labeled in red as "HR (ART)." PR alarm conditions annunciate as HR alarms.
Condition
Display
Value
Alarm
Grade
Message
Annunciation
Type
PR within limits
<NUM>
None
None
None
PR < LL
<NUM>
Medium
HR < LL
Persistent
PR > UL
<NUM>
Medium
HR > UL
Persistent
PR Bad Probe
---
Low
SpO
2
replace sensor
One Time
PR Cannot regulate LED
intensity (after start-up/standby)
<Blank>
None
None
Persistent
PR Cannot regulate LED
intensity (after finger in probe)
---
Low
SpO
2
/ HR check sensor
placement
Persistent
PR Pulsations Too Weak
---
Low
SpO
2
/ HR weak signal
Persistent
PR Probe is disconnected
(after start-up/standby)
<Blank>
None
None
Persistent
PR Probe is disconnected
(after finger in probe)
---
Low
SpO
2
/ HR unplugged
One Time
PR motion artifact
---
Low
SpO
2
artifact
Persistent
