Managing Alarms
FICO
2
out of range (high)
<Number >
Medium
CO
2
out of range (high)
Persistent
CO2 Unplugged (after start-
up/standby)
<Blank>
None
None
Persistent
CO2 Unplugged (after line
connected)
<Blank>
Low
CO
2
unplugged
One Time
Power up (10 to 30 seconds)
<Blank>
None
CO
2
warming up
Persistent
In Self-Maintenance Mode (auto-
zero)
<Blank>
None
CO
2
zeroing
Persistent
Module is purging the line
<Blank>
None
CO
2
purging line
Persistent
Line is occluded
---
Low
CO
2
occluded line
Persistent
H/W failure – module malfunction
---
Low
CO
2
problem detected
One Time
Calibration in progress
<Blank>
None
CO
2
calibrating
Persistent
Calibration completed – ok
N/A
Alert
CO
2
calibration ok
Alert
Calibration failed – supplied gas
is not close to expected value
N/A
Alert
CO
2
cal failed – wrong gas
Alert
Calibration failed – occlusion
during known gas sampling
N/A
Alert
CO
2
cal failed
Alert
Calibration failed – FilterLine
unplugged during calibration
N/A
Alert
CO
2
cal failed
Alert
IBP (P1 and P2) Conditions:
Note – P2 has the same conditions as P1. Substitute P1 with P2 as required in the
following table.
Condition
Display
Value
Alarm
Grade
Message
Annunciation
Type
Systolic pressure within limits
<Number>
None
None
Persistent
Systolic pressure < LL
<Number >
Medium
P1s < LL
Persistent
Systolic pressure > UL
<Number >
Medium
P1s > UL
Persistent
Mean pressure within limits
<Number>
None
None
Persistent
Mean pressure < LL
<Number >
Medium
P1m < LL
Persistent
Mean pressure > UL
<Number >
Medium
P1m > UL
Persistent
Diastolic pressure within limits
<Number>
None
None
Persistent
Diastolic pressure < LL
<Number >
Medium
P1d < LL
Persistent
Diastolic pressure > UL
<Number >
Medium
P1d > UL
Persistent
HR (ART) within limits
<Number>
None
None
Persistent
HR (ART) < LL
<Number >
Medium
HR < LL
Persistent
HR (ART) > UL
<Number >
Medium
HR > UL
Persistent
