Service Kit Installation Procedures
4–110 www.zoll.com 906-0731-04-01 Rev. C
36 Perform after successful Pre-Test (#35)
Apply a bead of RTV around the perimeter of the USB
connector board to create seal between Front Case
and board.
37 Position USB cable as indicated.
38 Re-assemble ventilator per instructions, and test/
calibrate using the RCS.
Step Procedure
