Ventilator & Calibration Troubleshooting
906-0731-04-01 Rev. C ZOLL Ventilator Service Manual 6–43
1012
Self Check Failure
O2 Valve Failure
Alarm occurs when the communication between the O
2
valve and the
SPM fails and the compressor is not available to provide ventilation.
Smart Pneumatic Module/
Vent Assembly Service Kit
1020
Low O2 Supply Failure
Alarm occurs when the O
2
supply pressure is < 35 psig
(241 kPa) and the compressor is not available to support ventilation.
Smart Pneumatic Module/
Vent Assembly Service Kit
1030
Gas Intake Failure
Alarm occurs when the Fresh Gas/Emergency Air Inlet is blocked so that
the compressor is not able to deliver flow sufficient for the current
settings and high pressure O
2
is not available to support ventilation.
Smart Pneumatic Module/
Vent Assembly Service Kit
1041
High O2 Supply Failure
Alarm triggers when the O
2
supply pressure is > 80 psig
(552 kPa).
Lower oxygen input pressure
1051
Self Check Failure
Run-Time Calibration Failure
Alarm triggers when the autocal procedure is not able to zero the airway
pressure transducer to ambient pressure.
Smart Pneumatic Module/
Vent Assembly Service Kit
1052
Self Check Failure
Communication between the airway pressure sensor and the SPM is lost.
Smart Pneumatic Module/
Vent Assembly Service Kit
1060
Exhalation System Failure
Alarm occurs when the PIP fails to return to the baseline pressure for 3
consecutive breaths, indicating that the exhalation control valve has
failed. When triggered, the device stops ventilating and attempts to
discharge the pressure in the breathing circuit to atmosphere. A
significant blockage of the exhalation valve or an occlusion/kink in the
exhalation valve tube mat cause this failure.
Smart Pneumatic Module/
Vent Assembly Service Kit
1061
Exhalation System Failure
The airway pressure, PIP, is > 40 cm H
2
O, the PIP High Limit (when PIP
High Limit is < 35 cm H
2
O) for > 5 seconds, or when the PIP is > 75 cm H
2
O
for > 1.5 seconds. When this happens, the device stops ventilating and
attempts to discharge the pressure in the breathing circuit to atmosphere.
A significant blockage of the exhalation valve or an
occlusion/kink in the exhalation valve tube may cause this failure.
Smart Pneumatic Module/
Vent Assembly Service Kit
1172
Self Check Failure
Alarm occurs when the 5 volt power bus fails to provide the required
voltage.
Smart Pneumatic Module/
Vent Assembly Service Kit
Service Code Associated Alarm Name/Description Service Kit/Resolution
