ZOLL EMV+ - Page 216

Ventilator & Calibration Troubleshooting
6–44 www.zoll.com 906-0731-04-01 Rev. C
1173
Self Check Failure
Alarm occurs when communication fails between one of the
subcomponents and the host processor.
Check cable from PIM board
to CPU
Smart Pneumatic Module/
Vent Assembly Service Kit
1174
Self Check Failure
Failure of PGA offset control detected during startup
Alarm occurs when the device is not able to calibrate the one or more
transducers and is no longer able to operate safely.
Smart Pneumatic Module/
Vent Assembly Service Kit
1175
Self Check Failure
Alarm triggers when the internal communication bus and the host are not
able to communicate with the sub-assemblies.
If this failure occurs, the user should manually ventilate the patient,
replace the ventilator, and contact the ZOLL Technical Service Department
for additional information.
Smart Pneumatic Module/
Vent Assembly Service Kit
1176
Self Check Failure
Alarm triggers when the calibration file fails its integrity check.
Smart Pneumatic Module/
Vent Assembly Service Kit
1420
Self Check Failure
Complete Power Failure
Alarm triggers when power is lost from both the internal battery and an
external source during operation. When this occurs, the LCD blanks (no
power for operation), the audible alarm pulses rapidly, and the visual
alarm flashes rapidly.
This alarm will last approximately two minutes. If the device can be
recharged after the failure and there are no other issues, you can return
the ventilator.
Smart Pneumatic Module/
Vent Assembly Service Kit
1430
Drained Battery
Alarm triggers when the internal battery power drops below the amount
required to provide ventilation and external power is not connected.
When this occurs there is enough power to operate the user interface and
provide information to the user.
Battery Replacement Service
Kit
1471
Self Check Failure
Alarm triggers when the device is no longer able to communicate with the
User Interface Module (UIM) and the interface controls.
Check Flex cable to LCD
CPU/UIM and SPO Stack
Service Kit
1472
Self Check Failure
Alarm triggers when the device is no longer able to communicate with the
Smart Pneumatic Module (SPM).
Check cable from PIM board
to CPU
Power Interface Module
Service Kit
1473
Self Check Failure
Alarm triggers when no valid data is sent from the SPM within 1 second.
Check cable from PIM board
to CPU
Power Interface Module
Service Kit
Service Code Associated Alarm Name/Description Service Kit/Resolution
