Ventilator & Calibration Troubleshooting
6–54 www.zoll.com 906-0731-04-01 Rev. C
3316
Invalid Pulse Ox Sensor
Alarm triggers when the pulse oximeter does not recognize the connected
sensor, i.e. a non-Masimo sensor. The alarm can also occur when there is a
broken sensor cable, inoperative LEDs, a fault is detected, and/or the sensor
has failed.
CPU/UIM and SPO Stack
Service Kit
3317
Low SpO2 Perfusion
Alarm triggers whenever the amplitude of the arterial pulsation is weak.
CPU/UIM and SPO Stack
Service Kit
3318
Low SpO2 Perfusion
Alarm triggers when the pulse oximeter determines the quality of the input
signal is low due to excessive motion or artifact.
CPU/UIM and SPO Stack
Service Kit
3421
External Power Low /Disconnect
Alarm triggers when the external power (either AC or DC) drops below
minimum level (~11 VDC as supplied by either the AC/DC Power Supply or a
direct DC source) or power is intentionally disconnected.
Power Interface Module
Service Kit
3422
Battery Fault
Alarm triggers when the internal battery has been removed or
communication between the battery and CPU has failed. When external
power is applied the device is capable of operation however, loss of external
power will result in loss of ventilation and a high priority alarm.
4 Year Maintenance Kit
Power Interface Module
Service Kit
3423
Battery Charging Fault
Alarm triggers when the battery charging circuit fails. When this alarm is
active, the battery cannot be charged. The device can only run with external
power. If power is lost, ventilator will stop and a high priority alarm will
trigger.
Power Interface Module
Service Kit
3430
Low Battery
Alarm triggers when the device detects that there is < 30 minutes of battery
operation remaining and no external power is connected.
4 Year Maintenance Kit
3431
Low Battery
Alarm triggers when external power is connected to a device that has an
internal battery that has drained to low battery status. The device is
warning the user that in the event of an external power failure the device
has < 30 minutes of backup.
4 Year Maintenance Kit
3441
External Power Fault
Alarm triggers when the supplied DC power is > 33 VDC. When this occurs,
the device automatically switches to operation using the internal battery. If
the supplied voltage drops to < 30 VDC, the device automatically returns to
operation using external power. If the external power source is known to be
good, then the AC/DC Power Supply may be faulty and need replacement.
Power Interface Module
Service Kit
3442
External Power Fault
Alarm triggers when the external power supply has insufficient current.
When this occurs, the device automatically switches to operation using the
internal battery. If the external power source is known to be good, then the
AC/DC Power Supply may be faulty and need replacement.
Power Interface Module
Service Kit
Service Code Associated Alarm Name/Description Service Kit/Resolution
