Chapter 17 SMS
LTE3302-M432 & LTE3312-M432 User’s Guide
123
17.2.2 SMS > SMS Inbox
Click the SMS Inbox button in the SMS screen to open the following screen. Use this screen to see the log
of the SMS text messages sent.
Figure 84 Configuration > Application > SMS > SMS Inbox
The following table describes the labels in this screen.
Text Message Enter the message content. You can type up to 160 characters in one message. If the message
exceeds 160 characters, more than one SMS will be sent. The maximum number of SMS that can
be sent is 20 (1400 characters total).
Result This shows whether the message is sent successfully.
Refresh Click this button to update the screen.
Apply Click this button to save your changes to the LTE Device.
Table 55 Configuration > Application > SMS > New SMS (continued)
LABEL DESCRIPTION
Table 56 Configuration > Application > SMS > SMS Inbox
LABEL DESCRIPTION
SMS Inbox List
Refresh Click this button to update the list.
Delete Click this button to delete an entry.
Close Click this button to hide the SMS Inbox List.
ID This field displays the index number of the message.
From Phone
Number
This field displays the mobile phone number from which the message is sent.
Timestamp This field displays the date and time the message was received.
SMS Text
Preview
This field displays the content of the message.
Actions Click the delete icon to remove the message record.
Refresh Click this button to update the screen.
Apply Click this button to save your changes to the LTE Device.
