LTE3311 Series User’s Guide
105
CHAPTER 13
Interface Group
13.1 Overview
By default, the four LAN interfaces on the LTE3311 are in the same group and can communicate
with each other. Creating a new interface will create a new LAN bridge interface (subnet) (for
example, 192.168.2.0/24) that acts as a dependent LAN network, and is a different subnet from
default LAN subnet (192.168.1.0/24).
13.2 Interface Group Screen
You can manually add a LAN/WLAN interface to a new group.
Use the DHCP screen to configure the private IP addresses the DHCP server on the LTE3311
assigns to the clients in the default and/or user-defined groups. See Chapter 9 on page 86 for more
information.
Use the Interface Group screen to create a new interface group, which is a new LAN bridge
interface (subnet). Click Network > Interface Group to open the following screen.
Figure 68 Network > Interface Group
The following table describes the fields in this screen.
Table 46 Network > Interface Group
LABEL DESCRIPTION
Add Click this button to create a new interface group.
Name This shows the descriptive name of the group.
LAN Interface This shows the interface group.
VID This shows the VLAN ID number (from 0 to 4094) of the interface group.
Modify Click the Delete icon to remove the user-defined group.
