2N Helios IP User Manual

Display-Equipped 2N® Helios IP Control as Viewed by External User
4.2
105
Calling to Number
If the Telephone function enable is selected (see Miscellaneous), 2N
®
Helios IP
can be used for calling to selected telephone numbers in a standard way. Push * in
the Electronic name tag mode to move to this mode.
Push the quick dialling button 3 or the # button to return to the electronic name tag
mode. To dial and display the number to be called, use the numeric keypad and push
* for confirmation. Push the quick dialling button 6 to delete and re-enter the last-
dialled number if necessary.
Telephone Directory
A structured telephone directory as defined by the display program is displayed in the
telephone directory mode. To browse through the telephone directory use the numeric
keypad arrow keys (i.e. keys 2, 4, 6 and 8). Use the up and down arrows to move
between the items. Push the right arrow to establish a call or move to a subgroup. The
* key and quick dialling buttons 4 and 5 have the same function as the right arrow.
Use the left arrow to return to the superior group.
3-line telephone directory
4-line telephone directory
You can also use the telephone directory for retrieving contacts. Push the quick
dialling button 6 to switch on the phone directory searching mode.
To retrieve a text, use the numeric keypad. The text to be searched is displayed in the
centre of the status line. To delete the last character push the quick dialling button 3.
Entering the text to be searched
Selecting one of the contacts found

2N Helios IP Specifications

General

Type	IP Intercom
Connectivity	Ethernet
Tamper Switch	Yes
Audio	Full duplex
Microphone	Built-in
Speaker	Built-in
Camera	Yes
Power Supply	PoE
Operating Temperature	+60°C
Ingress Protection	IP54
Protocols	SIP, RTSP, ONVIF
Audio Codec	G.711, G.722
Installation	Surface mount, flush mount (depending on model)
