2N Helios IP User Manual

Quick Configuration for Calling
3.2
49
SIP Parameter Setting
Set your VoIP network parameters to make calls from your 2N
®
Helios IP. To do this,
use the Other settings –> SIP setting menu.
Display name
Set the name to be displayed to the called subscriber. The name will also be
displayed in the right-hand upper corner of the web interface and used for
2N
®
Helios IP identification in the 2N
®
Helios IP Network Scanner application.
User ID
Set the user name to be used for registration.
Domain
Set the domain name or IP address of the server to be used for calling.
Use authorisation ID
Define whether the authorisation ID or user ID shall be used for authorisation.
Authorisation ID
Set the authorisation ID to be used for authorisation if the Use authorisation ID is
set to Yes.
Password
Define the authorisation password for registration and calling.
Local SP port
Set the port to be used by 2N
®
Helios IP for SIP signalling.
Proxy address
Set the SIP proxy address to be used by 2N
®
Helios IP for calling.
Proxy port
Set the SIP proxy communication port for SIP signalling.
2N
®
Helios IP registration
Define whether 2N
®
Helios IP should register at the SIP proxy.
Registration restricted to:
Set the time for 2N
®
Helios IP registration.
Registrar address:
Set the registrar address.
Registrar port:
Set the registrar communication port.

2N Helios IP Specifications

General

Type	IP Intercom
Connectivity	Ethernet
Tamper Switch	Yes
Audio	Full duplex
Microphone	Built-in
Speaker	Built-in
Camera	Yes
Power Supply	PoE
Operating Temperature	+60°C
Ingress Protection	IP54
Protocols	SIP, RTSP, ONVIF
Audio Codec	G.711, G.722
Installation	Surface mount, flush mount (depending on model)
