2N Helios IP User Manual

Technical Parameters
5.1
112
5.1 Technical Parameters
Power Supply
PoE 802.3af
48 V / 380 mA DC
or
Power supply adapter
230 V 10%, 50/60 Hz / 12V DC
DC power supply
12 V / 1A DC
VoIP
Signalling
SIP
Count of channels
2
Audio codecs
G.711 PCM, 64 kbps
Video codecs
H. 264, 64 – 2048 kbps
Interfaces
Ethernet
Connector
Terminal block plug
Network type
10/100 BASE-T
Relay outputs
Maximum voltage
30 V AC/DC
Maximum current
1 A AC/DC
Others
Dimensions
210×100×29 mm (h×w×d)
Weight
up to 500 g
Operational temperature range
–40 to +50 ºC
Coverage
IP53

2N Helios IP Specifications

General

Type	IP Intercom
Connectivity	Ethernet
Tamper Switch	Yes
Audio	Full duplex
Microphone	Built-in
Speaker	Built-in
Camera	Yes
Power Supply	PoE
Operating Temperature	+60°C
Ingress Protection	IP54
Protocols	SIP, RTSP, ONVIF
Audio Codec	G.711, G.722
Installation	Surface mount, flush mount (depending on model)
