Mounting – Electrical Installation
2.3
28
Figure 2.11 Description of 2N
®
Helios IP connectors, PCB version 530v2
+
El. lock
932070E
932080E
932090E
+
Power
adapter
91341481E
Terminal block
–
12V / 2A DC
Configuration connector
Speaker
connector
Microphone
connector
Additional lock
connector
Connector for
extending modules
Camera
connector
Display
connector
+
+
–
