2N Helios IP User Manual

Configuration
3.3
70
Figure 3.20 SIP Settings
User Settings
Display name
The name to be displayed to the called party. The name will also be displayed in
the right-hand upper corner of the web interface and used for 2N
®
Helios IP
identification in the 2N
®
Helios IP Network Scanner application.
User ID
Set the user ID for registration.
Domain
Enter the domain name or IP address of the server to be used for calling.
Use authorisation ID
Set whether 2N
®
Helios IP should use the authorisation ID or user ID only for
authorisation.
Auth ID
Enter the authorisation ID to be used for authorisation if the Use authorisation ID
parameter is set to Yes.

2N Helios IP Specifications

General

Type	IP Intercom
Connectivity	Ethernet
Tamper Switch	Yes
Audio	Full duplex
Microphone	Built-in
Speaker	Built-in
Camera	Yes
Power Supply	PoE
Operating Temperature	+60°C
Ingress Protection	IP54
Protocols	SIP, RTSP, ONVIF
Audio Codec	G.711, G.722
Installation	Surface mount, flush mount (depending on model)
