8. (1) Push the front of the cartridge into place. (2) Then, push the cartridge
handle downward until the cartridge is fully seated in its mount. Select the
checkmark to continue.
NOTE: Ensure the front of the cartridge (A) where the material exits
is seated under the clamp roller and between the vertical alignment
pins in the cartridge bay.
CAUTION: If replacing the third cartridge, be sure to rotate the
second bay cartridge to its vertical position before selecting the
checkmark.
NOTE: The print pad must be calibrated before printing your rst
creation. For more information, refer to the following section titled
Calibrate Print Pad.
A
1
2
