Parameters 119
32.46 Supervision 5
action
Selects whether the drive generates a fault, warning or
neither when the value monitored by signal supervision 5
exceeds its limits.
Note: This parameter does not affect the status indicated by
32.01 Supervision status.
No action
No action No warning or fault generated. 0
Warning Warning A8B4 Signal supervision 5 is generated. 1
Fault Drive trips on fault 80B4 Signal supervision 5.2
Fault if running Drive trips on fault 80B0 Signal supervision 1 if the motor is
running.
3
32.47 Supervision 5
signal
Selects the signal to be monitored by signal supervision
function 5.
For the available selections, see parameter 32.07
Supervision 1 signal.
Zero
32.48 Supervision 5 filter
time
Defines a filter time constant for the signal monitored by
signal supervision 5.
0.000 s
0.000 … 30.000 s Signal filter time. 1000 = 1 s
32.49 Supervision 5 low Defines the lower limit for signal supervision 5. 0.00
-21474836.00…
21474836.00
Low limit. -
32.50 Supervision 5 high Defines the upper limit for signal supervision 5. 0.00
-21474836.00…
21474836.00
Upper limit. -
32.51 Supervision 5
hysteresis
Defines the hysteresis for the signal monitored by signal
supervision 5.
0.00
0.00…100000.00 Hysteresis. -
32.55 Supervision 6
function
Selects the mode of signal supervision function 6. Determines
how the monitored signal (see parameter 32.57) is compared
to its lower and upper limits (32.59 and 32.50 respectively).
The action to be taken when the condition is fulfilled is
selected by 32.56.
Disabled
Disabled Signal supervision 6 not in use. 0
Low Action is taken whenever the signal falls below its lower limit. 1
High Action is taken whenever the signal rises above its upper
limit.
2
Abs low Action is taken whenever the absolute value of the signal falls
below its (absolute) lower limit.
3
Abs high Action is taken whenever the absolute value of the signal
rises above its (absolute) upper limit.
4
Both Action is taken whenever the signal falls below its low limit or
rises above its high limit.
5
Abs both Action is taken whenever the absolute value of the signal falls
below its (absolute) low limit or rises above its (absolute) high
limit.
6
Hysteresis Action is taken whenever the signal falls below its (hysteresis)
low limit or rises above its (hysteresis) high limit.
7
No. Name/Value Description Def/FbEq16
